AM14U Family XL End Plate

AM14U Family XL End Plate

This sheet metal plate makes up the end plate of the AM14U family of drive chassis.
  • Description
  • This plate captures the Inner and Outer plate and provides a surface to mount upper structures.
    • Height: 3.33 in.
    • Hole Size: 0.210 in.
    • Length: 38.0 in.
    • Lower Flange Length: 1.375 in.
    • Lower Hole Pattern: 0.5 in. Spacing
    • Material: 5052 Aluminum
    • Thickness: 0.125 in.
    • Upper Flange Length: 2.125 in.
    • Upper Hole Pattern: Two rows 1.0 in. apart, 0.5 in. between holes in each row
$50.00
AM14U Family XL End Plate—
$50.00

More Images

AM14U Family XL End Plate - Image 2

AM14U Family XL End Plate

This sheet metal plate makes up the end plate of the AM14U family of drive chassis.
  • Description
  • This plate captures the Inner and Outer plate and provides a surface to mount upper structures.
    • Height: 3.33 in.
    • Hole Size: 0.210 in.
    • Length: 38.0 in.
    • Lower Flange Length: 1.375 in.
    • Lower Hole Pattern: 0.5 in. Spacing
    • Material: 5052 Aluminum
    • Thickness: 0.125 in.
    • Upper Flange Length: 2.125 in.
    • Upper Hole Pattern: Two rows 1.0 in. apart, 0.5 in. between holes in each row

Product Information

Shipping & Returns

Description

This sheet metal plate makes up the end plate of the AM14U family of drive chassis.
  • Description
  • This plate captures the Inner and Outer plate and provides a surface to mount upper structures.
    • Height: 3.33 in.
    • Hole Size: 0.210 in.
    • Length: 38.0 in.
    • Lower Flange Length: 1.375 in.
    • Lower Hole Pattern: 0.5 in. Spacing
    • Material: 5052 Aluminum
    • Thickness: 0.125 in.
    • Upper Flange Length: 2.125 in.
    • Upper Hole Pattern: Two rows 1.0 in. apart, 0.5 in. between holes in each row
